Bently Nevada 3500/64M Dynamic Pressure Monitor 3500-64M

Description

.Many products are not yet on the shelves please contact us for more products

.If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation

.We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

Bently Nevada 3500/64M Dynamic Pressure Monitor Machinery Condition Monitoring.The 3500/64M Dynamic Pressure Monitor is a single slot, fourchannel monitor that accepts input from high temperature pressure transducers and uses this input to drive alarms. The monitor’s one measured variable per channel is bandpass dynamic pressure.

The 3500/64M can use the 3500 Rack Configuration Software to configure the bandpass corner frequencies along with an additional notch filter. The monitor provides a recorder output for control system applications.

The primary purpose of the 3500/64M Dynamic PressureMonitor is to provide the following:

1. Machinery protection by continuously comparingmonitored parameters against configured alarmsetpoints to drive alarms
2. Essential machine information for operations andmaintenance personnel

Each channel, depending on configuration, conditions its inputsignal to generate various parameters called measuredvariables. You can configure alert and danger setpoints foreach active measured variable.

Low and high filtering modes are options for achannel pair. Channels 1 and 2 form a pair, andchannels 3 and 4 are the other pair. You mayselect different band pass options on eachchannel of a channel pair. However, the channelswithin the pair must operate in the samefiltering mode.

You can set up the signal processing so that themonitor feeds only the channel 1 input to allfour channels. This feature is called CascadeMode and is denoted as 1 >ALL in the 3500Rack Configuration Software.

In Cascade Mode, you can select filter modeoptions for a channel pair only. One transducerprovides input to four channels for differentfiltering requirements. As a result, you canconfigure four separate bandpass filter optionsand four separate full-scale ranges with onetransducer input.The two modes of filtering provide differentqualities of filtering.
